TECHNICAL SPECS
Merits Power Wheelchair P321
- Test Weight capacity: 250lbs
- Super light and easy disassembly for storage and transportation
- Wireless electronic connector
- Ideal as personal secondary portable power wheelchair
- Compact size to easily fit into the trunk of most cars
- Ultra strong steel frame with limited lifetime warranty
- Adjustable height armrests
- Colors Available: Standard:Red, Blue Deluxe: Pink, White and Turquoise
DIMENSIONS
| Standard | Deluxe | |
| Seat Width | 17" | 17" |
| Seat Depth | 15" | 15" |
| Seat Height | 18"-21" | 18"-21" |
| Backrest Height | 15" | 15" |
| Min. Footrest Extension | 13" | 13" |
| Max. Footrest Extension | 17" | 17" |
| Overall Length | 34" | 34" |
| Overall Height | 33" | 33" |
| Overall Width | 22" | 22" |
| Total Weight | 100 lbs | 113 lbs |
| Capacity | 250 lbs | 300 lbs |
TECHNICAL SPECS
| Max Speed |
4mph |
| Range | up to 9 miles / 12 miles |
| Turning Radius |
23" |
| Ground Clearance |
2.25" /1.8" |
| Motor | DC 24V, 90W |
| Controller |
PG VSI 50A |
| Battery |
12V/14AHx2pcs or 12V/22AHx2 |
| Charger |
1.5A off-board |
| Gradient |
6° |
| Casters |
6" or 7" solid tires |
| Drive Wheels | 8" x 3" solid tires |
| Brakes |
intelligent, regenerative, electromagnetic |
